• Nearly 1,000,000 power battery packs has been delivered

    We provide batteries with different specifications and also available for flexible customization.

Product Advantages

  • Horwin provide the optional batteries with 5 specifications -72V/27Ah,72V/30Ah, 72V/36Ah, 72V/45Ah and 72V/46Ah.
    Five Specifications
    Horwin provide the optional batteries with 5 specifications -72V/27Ah,72V/30Ah, 72V/36Ah, 72V/45Ah and 72V/46Ah.
  • LFP battery with low cost and long service life; NCM battery with stronger power and higher energy density.
    Two Materials
    LFP battery with low cost and long service life; NCM battery with stronger power and higher energy density.
  • AEC-Q certified battery cell, 30 BMS function protection.
    High Security
    AEC-Q certified battery cell, 30 BMS function protection.
  • Waterproof rating can be IP67.
    Waterproof
    Waterproof rating can be IP67.
  • Lighter than lead-acid batteries, and much portable.
    Less Weight
    Lighter than lead-acid batteries, and much portable.
  • Performance can still keep above 80%</br>even after 1,500 charging cycles.
    Longer Battery Life
    Performance can still keep above 80%
    even after 1,500 charging cycles.

High customizability of batteries

Battery capacity, power performance, color scheme, SaaS services and functions can be flexibly customized according to demands.

Product Specification

Measurements
Model 72V27AH 72V30AH 72V36AH 72V36AH 72V45AH 72V46AH
Material LFP battery LFP battery LFP battery NCM battery NCM battery LFP battery
Battery pack nominal capacit 27Ah 30Ah 36Ah 36Ah 45Ah 46Ah
Nominal Voltage 72V 72V 72V 72V 72V 72V
Charging temperature range 0-50℃ 0~45℃ 0~50℃ 0~55℃ 0~45℃ 0-55℃
Battery Final Dimension 266*158*289.5mm±1mm 266*158*307mm±1mm 290*157*265mm±1mm 266*157.96*289.5mm±1mm 266*158*289.5mm±1mm 332*319*258.5mm±2mm
Weight ≤18.5kg ≤19.7kg ≤17.5kg ≤18.85kg ≤18.3kg ≤32kg
Waterproof level IP67 IP67 IP67 IP67 IP67 IP67
Storage Temperature ≤1month: -20~60℃ ≤3months: -20~40℃ ≤1 year: -20~20℃ ≤1month: -20~60℃ ≤3months: -20~45℃ ≤1 year: -20~25℃ ≤1month: -20~60℃ ≤3months: -20~40℃ ≤1 year: -20~20℃ ≤1month: -20~60℃ ≤3months: -20~35℃ ≤1 year: -20~25℃ ≤1month: -10~55℃ ≤3months: -10~45℃ ≤1 year: 0~30℃ -20-45°℃(≤3 months)25±5°℃(≥3 months)
Storage Humidity 0~70% RH 60±20%RH 0~70% RH 65%±20%RH 10%~95%RH 65%±20%RH
